ANTSPACE MD5 – Immersion‑Cooling Mining Container

ANTSPACE MD5 container hosts 160 immersion miners with a 1000kW load, SPOT shipping in 60 days, and a 365‑day warranty.

ANTSPACE MD5 Overview

The Bitmain ANTSPACE MD5 is an immersion‑cooling mining container designed for SHA‑256 miners such as the S21 Immersion and S21 XP Immersion models. With a maximum load of 1000 kW and space for 160 miners, it provides industrial‑scale mining infrastructure with efficient cooling and compliance certifications.

Key Specifications

• Miner Capacity: 160 units (S21 Imm. & S21 XP Imm.)
• Operating Power: 1000 kW
• PUE @ 25 °C ambient: 1.06
• Input Voltage: 400V ±5%, 50/60 Hz
• Dimensions: 12192 × 2438 × 2896 mm
• Weight: 12 t shipping / 18.5 t operating
• Main Switch Capacity: 1200 A × 2
• Rated Current: 952 A (A) / 866 A (B)
• Rated Current per Miner: 20 A
• Cooling Tower Interface: DN65 (ISO2852 PN16)
• Dry Tower Specs:
  • Dimensions: 12192 × 2438 × 2896 mm
  • Operating Power: 100 kW
  • Outlet Temp: 35 °C @ 30 °C ambient
  • Noise Level: 70 dBA @ 15 m
  • Pipe Material: 304 stainless steel

Certifications

• China Classification Society Certification
• NFPA 79:2024
• UL 508A:2018 R7.22
• CSA C22.2 No.301:23
• ANSI/ISO 12100:2012
• EN ISO 12100:2010
• EN 60204‑1:2018

🛒 Purchasing Guidelines

• Price: $180,000 per unit
• Payment Methods: USD, BTC, ETC, USDT (ERC20/TRC20)
• Availability: SPOT shipping within 60 working days after full payment
• Customs: Buyers must prepare proper documentation; cancellations or refunds are not accepted after order submission
• Images: Product photos are for reference only; final shipment version may differ

🚚 Shipping Details

• Dispatch: First‑paid, first‑shipped basis
• Responsibility: Buyer must handle customs clearance and documentation
• Certificates: Certificates of Conformity available for download

🛡 Warranty

• Coverage: 365 days from shipping date
• Includes: Replacement shipping costs covered by Bitmain within warranty period
• Exclusions: Resold units, improper installation, unauthorized modifications

⚠️ Buyer Considerations

• Requires 400V ±5% input
• Ground must withstand ≥14 t load
• Needs 15 t crane for unloading container and cooling tower
• Leave ≥4 m air intake space around cooling tower
• Operating environment: −25 °C to 40 °C, humidity 10–90% RH, altitude ≤3000 m
• Power derating required above 1000 m altitude (−1% per 100 m)
• Coolant must be pre‑heated to ≥20 °C before starting miners
